Talpa LH 217
Designed for underground galleries, the LH 217 loaders provide maximum value with their customer oriented designs.
- Excellent maneuvering and operation performance
- High/Low damping level with option
- Short cycle time
- Efficient loader characteristic
- Various bucket options for different operations
- DANA powershift transmission
- Robust steel structure
- Constant ground contact with oscillating rear axle
- Catalytic converter and spark arrester
- Optional fire suppression system
- Oil cooled, fail-safe (SAHR) brakes
- Kessler axles with planetary hub reduction
- Optional central lubrication
Engine | |
Engine | Tier 3/EU III A |
Power rating | Deutz 92 kW/2100 rpm – Turbo |
Number of cylinder | 4 |
Cooling system | Su / Water cooled |
Exhaust system | Katalitik konverter / Catalytic converter |
Air cleaner | Evet / Yes |
Exhaust silencer | Evet / yes |
Radiator | Evet / Yes |
Drive Line | |
Transmission brand | DANA |
Gears Forward | 3 |
Gears Reverse | 3 |
Torque brand | DANA |
Axles brand | Kessler |
Degree of axle oscillation | +/-8° |
Brake type | SAHR |
Tyres | |
Dimension | 12.00R20 |
Canopy | |
Canopy (ROPS/FOPS certificate) | Evet / Yes |
Steering control | Joystick |
Electrical system | |
Battery | 2 X 105 A |
Alternator | 80 A |
System voltage | 12V |
Lights (LED) | 2 Ön, 2 Arka / 2 Front, 2 Rear |
Hydraulic system | |
Main pump | Tandem Dişli Pompalı / Tandem gear pump |
Hydraulic tank capacity | 140 Lt |
Maunual hyd.tank fill pump | Evet / Yes |
Filtration type | Emme / Suction |
Control System | |
Type | Manuel kontrollü / Manual control |
Fuel | |
Fuel tank capacity | 190 lt |
Fuel filter | Evet / Yes |
Other | |
Back-up alarm | Evet / Yes |
Central manual lubrication system | Opsiyonel / Optional |
Manual lubrication system | Evet / Yes |
Fire extinguisher | Evet / Yes |
Tramming capacity | |
Operating Weight | 8950 kg |
Bucket Capacity | 3500 kg / 1.7m³ |
Total Loaded Weight | 12450 kg |
Dimension | |
Length | 7497 mm |
Height | 2000 mm |
Width | 1650 mm |
Certificates | |
CE Certificate | Evet / Yes |
EN ISO 3471:2008 ROPS | Evet / Yes |
EN ISO 3449:2008 FOPS | Evet / Yes |
* Manufacturer reserves the right to change the specifications above.
