Talpa LH 425
Предназначенные для подземных галерей, погрузчики LH 425 предлагают качество самого высокого уровня с уникальным дизайном, ориентированным на клиента.
- Excellent manoeuvring and operation performance
- Robust steel structure
- Constant ground contact with oscillating rear axle
- Catalytic converter
- Optional fire suppression system
- Oil cooled, fail-safe (SAHR) brakes
| Engine | Tier 3/EU III A |
| Power Rating | Option 1 : Mercedes OM926 220 kW/2200 rpm |
| Option 2 : Volvo TAD850 210kW @ 2200rpm | |
| Number of Cylinder | 6 |
| Cooling System | Water Cooled |
| Exhaust System | Catalytic Converter |
| Drive Line | |
| Transmission | DANA |
| Gears | 4 Forward 4 Reverse |
| Torque Converter | DANA |
| Axles | Kessler D101 |
| Degree of Axle Oscillation | +/-8° |
| Brake Type | SAHR |
| Tyres | |
| Dimension | 18.00R25 |
| Canopy | |
| Canopy | Closed Cabin with A/C & Heating |
| ROPS/FOPS approved | Yes |
| Steering Control | Joystick |
| Electrical System | |
| System voltage | 24V |
| Control System | |
| Type | Electrohydrolic (PWM) |
| Remote control | Optional – HBC Radiomatic |
| Other | |
| Back-up alarm | Yes |
| Central lubrication system | Optional |
| Fire extinguisher | Yes |
| Operating capacity (kg) | 28 000 |
| Payload capacity (kg) | 10 000 |
| Bucket (m3) | 4 |
| Length (mm) | 9 825 |
| Width (mm) | 2 528 |
| Height – Canopy (mm) | 2 380 |
* Производитель оставляет за собой право вносить изменения в вышеуказанные спецификации.
Для получения дополнительной информации, свяжитесь с нами.
